| Key Features |
- Complete solution for complex RF signal generation in a single box
- Direct generation of signals with carriers up to 4 GHz, removing the need for external RF conversion
- Simulate real-world analogue effects on high-speed digital data streams
- Generate high-precision RF signals
- Spurious Free Dynamic Range performance better than -70 dBc
- Create long complex waveforms without compromising bandwidth
- Up to 2 GSamples of Waveform Memory plays 400 ms of data at 5 GS/s and 800 ms of data at 2.5 GS/s
- Synchronize multiple units to achieve a multi-channel high-speed AWG system
- Fully operational without external PC
- Built-in display and buttons make it possible to quickly select, edit, play waveforms and trigger events directly from the
- AWG front panel
- Simulate real-world environments by playing back captured signals
- Waveforms captured with Oscilloscopes or Real-Time Spectrum
- Analyzers can be played back, edited or re-sampled on the AWG
- Smooth transition from simulation to the real-world testing environment
- Waveform vectors imported from third-party tools such as MATLAB
|
